| SKU | NM-EJM9D |
|---|---|
| Model ID | NPM-WX |
| Model No. | NM-EJM9D |
| PCB Dimensions (mm)* |
Single-lane Batch Mounting: L 50 × W 50 ～ L 750 × W 610 2-Position Mounting: L 50 × W 50 ～ L 350 × W 610 |
| PCB Dimensions (mm)* |
Dual-lane Dual transfer (Batch): L 50 × W 50 ~ L 750 × W 300 Dual transfer (2-position): L 50 × W 50 ~ L 350 × W 300 Single transfer (Batch): L 50 × W 50 ~ L 750 × W 590 Single transfer (2-position): L 50 × W 50 ~ L 350 × W 590 |
| Electric Source | 3-phase AC 200, 220, 380, 400, 420, 480 V 3.0 kVA |
| Pneumatic Source * |
Min. 0.5 MPa, 200 L /min（A.N.R.) [*1] |
| Dimensions (mm) * | W 1,410 mm [*2] × D 2,570 mm [*3] × H 1,444 mm [*4] |
| Mass |
2,740 kg (Only for main body : This differs depending on the option configuration. |
