八一>J又卜 PARTS LIST |
士>卜品番 Kit No. |
KXFK000HA00 |
tj)3〉NO. Section No. |
|
士>卜名称 Kit Name |
CPU㩷BOX&配線 CPU BOX & Wiring |
1 |
|
4j入卜 NO. Ref No. |
品番 Part No. |
品䇭䇭名 Part Name |
備䇭䇭䇭考 Remarks |
数量 Q'ty | R 1 |
R 2 |
R 3 |
| 1 | N610072911AA | BOX | SP60/80:CPU-BOX | 1 | |||
| 2 | N263ZUG2-023 | NOISE-FILTER | ZUG2206- 11S | 1 | S | ||
| 3 | KXFP02JAA00 | CIRCUIT-PROTECTOR | NRF110-8A | 1 | S | ||
| 4 | KXFP005AA00 | FAN | 109-601 | 1 | S | ||
| 5 | KXFP007AA00 | FAN-GUARD | 109-620 | 1 | |||
| 6 | KXFP6EA5A00 | POWER | R100U-5 | 1 | |||
| 7 | KXFP6E8AA00 | POWER | R50A-12 | 1 | S | ||
| 8 | KXFP6EA6A00 | POWER | R15A-12 | 1 | S | ||
| 9 | KXFP6ETXA00 | POWER | R50A-24 | 1 | S | ||
| 10 | N510021558AA | FLASH-DRIVE | SCG3-256MDG | 1 | |||
| 11 | KXFE0062A00 | PCB | MCMAET | 2 | |||
| 12 | KXFE000MA00 | PCB | PRMFEA | 1 | |||
| 13 | KXFE001JA00 | PCB | ELL2EA | 1 | |||
| 14 | N610025429AA | PCB | SCMZEP | 1 | |||
| 15 | KXFE001EA00 | PCB | EC14EA | 1 | |||
| 16 | N610001103AA | PCB | MTMJEB | 1 | |||
| 17 | KXFE0013A00 | PCB | NFM0CN | 1 | |||
| 18 | KXFE002TA00 | PCB | EC55CA | 1 |
|
八一>J又卜 PARTS LIST |
士>卜品番 Kit No. |
1G4CM0000 |
tj)3〉NO. Section No. |
|
士>卜名称 Kit Name |
子D他 OTHERS |
3-A |
|
4j入卜 NO. Ref No. |
品番 Part No. |
品䇭䇭名 Part Name |
備䇭䇭䇭考 Remarks |
数量 Q'ty | R 1 |
R 2 |
R 3 |
| 1 | KXFP005AA00 | FAN | 109-601 | 2 | S | ||
| 2 | KXFP007AA00 | FAN-GUARD | 109-620 | 2 | |||
| 3 | KXFP5Z1AA00 | KEY-BOARD | AB12C-6046/GE5 | 1 | |||
| 4 | KXFP019AA00 | SWITCH | AR22PR-220G | 2 | S | ||
| 5 | KXFP5HSAA00 | TERMINAL-BLOCK | BTBH30C4 | 1 | S | ||
| 6 | KXFP5WXAA00 | TERMINAL-BLOCK | BTBH30C5 | 1 | |||
| 7 | KXFP5XAAA00 | TERMINAL-BLOCK | BTBH30C8 | 1 | S | ||
| 8 | N510009985AA | TERMINAL-BLOCK | TM-212 | 1 | S | ||
| 10 | KXFE001KA00 | PCB | EC68CA | 1 | |||
| 11 | KXFP5ZDAA00 | FDD | YD-702D-6639D-011051 | 1 | |||
| 12 | KXFP6EADA00 | NF | FN3011-30-61 | 1 | S | ||
| 13 | N510011554AA | KEY-BOARD | FP-VM- 10-MO | 1 | |||
| 14 | KXFP594AA00 | PRINTER | KP-3UL | 1 | |||
| 15 | N510016346AA | BACK-LIGHT | CA5-BLU10T-01 | 1 | |||
| 16 | KXFP6F8NA00 | MAGNET-CONTACTOR | MSO-N10CX KP 3.6A COIL AC100V | 1 | |||
| 17 | KXFP6E8DA00 | MAGNET-CONTACTOR | MSO-N10CX KP 6.6A COIL AC100V | 1 | |||
| 18 | KXFE001NA00 | PCB | NF04CA | 4 | |||
| 19 | N510025310AA | BREAKER | NF100JWU 3P 30A | 1 | S | ||
| 21 | N610080211AA | PCB | PE1ACX | 1 | S | ||
| 22 | KXFP57QAA00 | SURGE-KILLER | R.A.V-781BXZ-2A | 1 | S | ||
| 23 | N510011524AA | SWITCH | XW1E-BV402MFR-TK2377 | 2 | S | ||
| 24 | N610043423AA | PATLITE | Three-color PATLITE LED RoHS_with 400mm Pole | 1 | |||
| 25 | KXFP6EAEA00 | SURGE-KILLER | UN-SA3310 | 2 | |||
| 26 | KXFP6CVAA00 | SWITCH-PARTS | V1SWUF | 1 | S | ||
| 27 | KXFP6G83A00 | POWER | PAA75F-24-RN | 1 | |||
| 28 | KXFP6EJHA00 | TRANS | TE3N-7.2K-GR | 1 | |||
| 29 | KXFP6EJJA00 | BREAKER | NF50-SWU 3P 20A | 1 | |||
| 30 | KXFP6DWAA00 | BREAKER | NF50-SWU 2P 3A | 1 | |||
| 31 | KXFP6D8AA00 | CP | CP31FS/7D | 1 | S | ||
| 33 | N510012676AA | SIGNAL-TOWER | #LCR-302FBW-RYG B0701 | 1 | S | ||
| 34 | N510023869AA | SIGNAL-TOWER-POLE | #SZR-80L-039 QC007 | 1 | |||
| 35 | N510027039AA | LED-LAMP-UNIT | B72100111- 1F1(Red) | 1 | |||
| 36 | N510027040AA | LED-LAMP-UNIT | B72100111-2F1(Yellow) | 1 | |||
| 37 | N510027041AA | LED-LAMP-UNIT | B72100111-3F1(Green) | 1 | |||
