Panasonic CM212 CM402 CM602 I/O Board N610140453AA NFV2CJ
Source:未知Author:Smotor Addtime:2023-06-19 Click:
Panasonic CM212 CM402 CM602 I/O Board N610140453AA NFV2CJ
パーツリスト
PARTS LIST |
キット品番
Kit No. |
N610008011AA |
ｾｸｼｮﾝNo.
Section No. |
キット名称
Kit Name |
CPU BOX:VME
CPU BOX:VME |
1 |
ｲﾗｽﾄ
No.
Ref
No. |
品番
Part No. |
品 名
Part Name |
備 考
Remarks |
数量
Q'ty |
R
1 |
R
2 |
R
3 |
|
1 |
KXFP5T3AA00 |
POWER |
R150U-5 |
1 |
|
S |
|
|
2 |
KXFP6EM4A00 |
POWER |
RMC50A-1 |
1 |
|
S |
|
|
3 |
KXFP005AA00 |
FAN |
109-601 |
1 |
|
S |
|
|
4 |
KXFP007AA00 |
FAN-GUARD |
109-620 |
1 |
|
|
|
|
5 |
KXFP6EB5A00 |
NOISE-FILTER |
FN9223-6-06 |
1 |
|
S |
|
|
6 |
KXFP02JAA00 |
CIRCUIT-PROTECTOR |
NRF110-8A |
1 |
|
S |
|
|
7 |
KXFE000BA00 |
PCB |
MTL1CA_PbF:LOCAL MOTHER BOARD |
1 |
|
|
|
|
8 |
KXFP5XHAA00 |
PCB-COM |
650-VME15TO |
1 |
|
|
|
|
9 |
N610012076AA |
PCB |
SCV1ER_PbF:SBC603(150MHz VVB1.0) |
1 |
|
S |
|
|
10 |
N610001129AA |
PCB |
PRV4EA_PbF:HGR-40 |
1 |
|
S |
|
|
11 |
N610011654AA |
PCB |
PRV4EB_PbF:HGR-40 |
1 |
|
S |
|
|
12 |
N610010912AA |
Board kit |
NFV2CF+NF0FCF |
1 |
|
S |
|
|
13 |
KXFK00APA00 |
PCB |
3401P3/Motion Controller: Support for FF |
1 |
|
S |
|
|
14 |
N610009178AA |
Board kit |
ELV3EA+ELV1ED |
1 |
|
|
|
|
15 |
N610010587AA |
UNIT |
|
0 |
|
|
|
|
16 |
N610012025AA |
UNIT |
|
1 |
|
|
|
|
17 |
KXFK002KA00 |
333PC0/LASER I/F |
333PC0/LASER I/F BOX BF : CM402ANRITSU |
1 |
|
|
|
|
18 |
KXFK002LA00 |
333QC0/LASER I/F |
333QC0/LASER I/F BOX BR : CM402ANRITSU |
1 |
|
|
|
|
19 |
KXFE0002A00 |
PCB |
NF0CCA_PbF: Laser_IF |
1 |
|
S |
|
|
|
|
|
|
|
|
|
|
CM212
CM212 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM212 PC-COM BOARD 660-VME15TKM-VE2 N510036830AA
CM212 PCB BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM212 PCB BOARD KIT ELV4EA+ELV3EA N610030275AA
CM212 PCB BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM212 PCB BOARDSCV4EB_PbF: HGR14 KXFE0009A00
CM212 PCB BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM212 PCB BOARD KIT NF0FCF+NFV2CG N610051792AA
CM212 PCB BOARD PNF0AF-AA N610012675AA
CM212 PCB BOARD NF5ACA KXFE000KA00
CM212 PCB BOARD NF3ACB N610012673AA
CM212 PCB BOARD PNF0AD-AA N610012674AA
CM212 PCB BOARD NF18CC N610052757AA
CM212 PCB BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM212 PCB BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM212 PCB BOARD NF2ECA KXFE00GTA00
CM212 PCB BOARD MC15CA KXFE0004A00
CM212 PCB BOARD MC14CB KXFE00F0A00
CM212 PCB BOARD MC16CB KXFE00GXA00
CM212 PCB BOARD MS21EA KXFE00GYA00
CM212 PCB BOARD NF8BCA KXFE00EZA00
CM212 PCB BOARD NF3ACB N610012673AA
CM212 PCB BOARD PNF0AD-AA N610012674AA
CM212 PCB BOARD EL1ACA KXFE000JA00
CM212 PCB BOARD PRV5EA_PbF:HGR41-3D N610042291AA
CM212 PCB BOARD PRV5EB_PbF:HGR41-3D N610042292AA
CM402
CM402 PC BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM402 PC BOARD NF18CA_PbF:Line Camera Switchover CNT Board KXFE001RA00
CM402 PC BOARD NF2ECA KXFE00GTA00
CM402 MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM402 PCB-COM 660-VME15TKM-VE2 N510036830AA
CM402 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM402 PC BOARD KIT ELV4EA+ELV3EA N610030275AA
CM402 PC BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM402 PC BOARD SCV4EB_PbF: HGR14 KXFE0009A00
CM402 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM402 PC BOARD KIT NF0FCF+NFV2CG N610051792AA
CM402 PC BOARD PNF0AF-AA N610012675AA
CM402 PC BOARD MC15CA KXFE0004A00
CM402 PC BOARD MC14CB KXFE00F0A00
CM402 PC BOARD MC16CB KXFE00GXA00
CM402 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
CM402 PC BOARD NF3ACB N610012673AA
CM402 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM402 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM402 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM402 PCB BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM602
CM602 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM602 PCB-COM 650-VME15TO KXFP5XHAA00
CM602 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM602 PC BOARD PRV4EA_PbF:HGR-40 N610001129AA
CM602 PC BOARD PRV4EB_PbF:HGR-40 N610011654AA
CM602 PC BOARD KIT NFV2CF+NF0FCF N610010912AA
CM602 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM602 PC BOARD KIT ELV3EA+ELV1ED N610009178AA
CM602 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM602 PC BOARD NF2ACB_PbF: Transport Controller I/O Load Board KXFE00FKA00
CM602 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM602 PC BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM602 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM602 PC BOARD PE1ACQ_PbF:LED Lighting Control Board N610017723AC
CM602 PC BOARD NF0ECB_PbF: Ring IO Load Board KXFE000EA00
CM602 PC BOARD MC15CA KXFE0004A00
CM602 PC BOARD MC14CB KXFE00F0A00
CM602 PC BOARD MC16CB KXFE00GXA00
CM602 PC BOARD PMC0AB-AA N610013410AA
CM602 PC BOARD NF3ACA_PbF: Collectively-changing truck controller KXFE000HA00
CM602 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
