Panasonic CM602 CM101 Vision Board N610001129AA PRV4EA2
Source:未知Author:Smotor Addtime:2023-05-17 Click:
Panasonic CM602 CM101 Vision Board N610001129AA PRV4EA2
パーツリスト
PARTS LIST |
キット品番
Kit No. |
N610022131AA |
ｾｸｼｮﾝNo.
Section No. |
キット名称
Kit Name |
CPU BOX_RoHS
CPU BOX_RoHS |
3 |
ｲﾗｽﾄ
No.
Ref
No. |
品番
Part No. |
品 名
Part Name |
備 考
Remarks |
数量
Q'ty |
R
1 |
R
2 |
R
3 |
|
1 |
KXFP5T3AA00 |
POWER |
R150U-5 |
1 |
|
S |
|
|
2 |
KXFP6EM4A00 |
POWER |
RMC50A- 1 |
1 |
|
S |
|
|
3 |
KXFP005AA00 |
FAN |
109-601 |
1 |
|
S |
|
|
4 |
KXFP007AA00 |
FAN-GUARD |
109-620 |
1 |
|
S |
|
|
5 |
KXFP006AA00 |
FAN-GUARD |
109-619 |
1 |
|
S |
|
|
6 |
KXFP00XAA00 |
CABLE |
489-086-L10 |
1 |
|
S |
|
|
7 |
N263ZUG2-023 |
NOISE-FILTER |
ZUG2206- 11S |
1 |
|
S |
|
|
8 |
KXFE000BA00 |
PCB |
MTL1CA_PbF:LOCAL MOTHER BOARD |
1 |
|
|
|
|
9 |
N510036830AA |
PCB-COM |
660-VME15TKM-VE2 |
1 |
|
|
|
|
10 |
N610012076AA |
PCB |
SCV1ER_PbF:SBC603(150MHz VVB1.0) |
1 |
|
S |
|
|
11 |
N610030275AA |
Board kit |
ELV4EA+ELV3EA |
1 |
|
S |
|
|
12 |
N610001129AA |
PCB |
PRV4EA_PbF:HGR-40 |
1 |
|
S |
|
|
13 |
N610011654AA |
PCB |
PRV4EB_PbF:HGR-40 |
1 |
|
S |
|
|
14 |
KXFK00APA00 |
PCB |
3401P3/Motion Controller:Support for FF |
1 |
|
|
|
|
15 |
N610051792AA |
Board kit |
NF0FCF+NFV2CG |
1 |
|
S |
|
CM101
CM101 PCB BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM101 PCB-COM 660-VME15TKM-VE2 N510036830AA
CM101 PCB BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM101 PCB BOARD KIT ELV4EA+ELV3EA N610030275AA
CM101 PCB BOARD PRV4EA_PbF:HGR-40 N610001129AA
CM101 PCB BOARD Motion Controller N610046333AA
CM101 PCB BOARD Motion Controller N610046333AA
CM101 BOARD KIT NF0FCF+NFV2CG N610051792AA
CM101 PCB BOARD PNF0AF-AA N610012675AA
CM101 PCB BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
CM101 PCB BOARD MC15CA KXFE0004A00
CM101 PCB BOARD MC14CB KXFE00F0A00
CM101 PCB BOARD PMC0AB-AA N610013410AA
CM101 PCB BOARD PPU0AB-AA N610044244AA
CM101 PCB BOARD NF2ECA KXFE00GTA00
CM101 PCB BOARD PNF0AJ N610034913AA
CM101 PCB BOARD NF18CC N610052757AA
CM101 PCB BOARD MC16CB KXFE00GXA00
CM101 PCB BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM101 PCB BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM101 PCB BOARD NF3ACB N610012673AA
CM101 PCB BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM101 PCB BOARD PRV5EA_PbF:HGR40-3D N610042291AA
CM602
CM602 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM602 PCB-COM 650-VME15TO KXFP5XHAA00
CM602 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM602 PC BOARD PRV4EA_PbF:HGR-40 N610001129AA
CM602 PC BOARD PRV4EB_PbF:HGR-40 N610011654AA
CM602 PC BOARD KIT NFV2CF+NF0FCF N610010912AA
CM602 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM602 PC BOARD KIT ELV3EA+ELV1ED N610009178AA
CM602 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM602 PC BOARD NF2ACB_PbF: Transport Controller I/O Load Board KXFE00FKA00
CM602 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM602 PC BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM602 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM602 PC BOARD PE1ACQ_PbF:LED Lighting Control Board N610017723AC
CM602 PC BOARD NF0ECB_PbF: Ring IO Load Board KXFE000EA00
CM602 PC BOARD MC15CA KXFE0004A00
CM602 PC BOARD MC14CB KXFE00F0A00
CM602 PC BOARD MC16CB KXFE00GXA00
CM602 PC BOARD PMC0AB-AA N610013410AA
CM602 PC BOARD NF3ACA_PbF: Collectively-changing truck controller KXFE000HA00
CM602 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
