パーツリスト PARTS LIST |
キット品番 Kit No. |
N610112727AA |
ｾｸｼｮﾝNo. Section No. |
|
キット名称 Kit Name |
本体部制御:NPM-D Main Body (H):NPM-D |
4 |
|
ｲﾗｽﾄ No. Ref No. |
品番 Part No. |
品 名 Part Name |
備 考 Remarks |
数量 Q'ty | R 1 |
R 2 |
R 3 |
| 1 | N610106335AB | Operation change board | NPM/AM100 Operation change board | 1 | S | ||
| 2 | N610113311AA | Ring I/O Load Board:NPM | PNF0B3-AA | 1 | S | ||
| 3 | N610113374AA | Connector Relay Board:NPM | PEC0AD-AA | 1 | S | ||
| 4 | N610072768AC | Serge protector | RAV-801BXZ-4(250)-TMEE2-5-TMEE1.25-4-250(2a/4a/6aF101) | 1 | S | ||
| 5 | N510031643AB | TERMINAL-BLOCK | TB-X101(F000035) | 1 | |||
| 6 | N510064051AA | BREAKER | NF100-SRU 3P 15A | 1 | S | ||
| 7 | N510064175AA | SWITCH-PARTS | F-05SRUL | 1 | S | ||
| 8 | N510035139AA | TERMINAL-COVER | TCS-05SRU3 | 1 | |||
| 9 | N510013513AA | TERMINAL | N510013513AA | 1 | |||
| 10 | N510050636AA | TRANSFORMER | TE3N-4.8K-GR/TD- 16672-A | 1 | S | ||
| 11 | N510063014AA | NOISE-FILTER | NF3020C-SVB | 1 | S | ||
| 12 | MCDDT3520N45 | MOTOR-DRIVER | MCDDT3520N45 | 2 | S | ||
| 13 | MEDDT7364N45 | MOTOR-DRIVER | MEDDT7364N45 | 2 | S | ||
| 14 | N510045220AB | RESISTOR | RH450F 20QJ2A225 | 2 | S | ||
| 15 | N510061463AA | CARD-READER | YD-8V06-G8H30513 | 1 | S | ||
| 16 | N510045262AA | GASKET | 65TSV7-7(KD3) L=100 | 2 | |||
| 17 | N510045263AA | GASKET | 65TSV7-7(KD3) L=132 | 4 | |||
| 18 | N510045264AA | GASKET | 65TSV7-7(KD3) L=172 | 1 | |||
| 19 | N510046909AA | GASKET | 65TSV7-7(KD3) L=540 | 2 | |||
