| BM122 | BM221 | ||
| Model No. | NM-MF12A | NM-MF11A | |
| PCB Dimensions Min L*W to Max L*W |
50*50mm 330*250mm |
||
| Max Speed | 0.19s/chip | 0.3s/chip | |
| Placement Accuracy | Chip 50μm(Cpk≥1），QFP 30μm（Cpk≥1） | ||
| No. Of Components Input | Double Tape Feeder:160 | Double Tape Feeder：120，Tray Feeder：80 | |
| Components Dimensions | 0201（0603）Chip to L 32mm x W 32mm x T 15mm(Selection Specification) | 0201（0603）Chip to L 150mm x W 25mm x T 25mm | |
| PCB Exchange Time*3 | 4.0s | ||
| Electric Source*4 | 3-phase AC 200V,3.3kVA | ||
| Pneumatic Source | 0.43MPa，150L/min(A.N.R.) | ||
| Dimensions |
1950mm 1500mm*4 1500mm*5 |
1950mm 2060mm*4 1500mm*5 |
|
| Mass | 1,700kg | 2,000kg | |
