八一>J又卜 PARTS LIST |
士>卜品番 Kit No. |
KXFK000HA00 |
tj)3〉NO. Section No. |
|
士>卜名称 Kit Name |
CPU㩷BOX&配線 CPU BOX & Wiring |
1 |
|
4j入卜 NO. Ref No. |
品番 Part No. |
品䇭䇭名 Part Name |
備䇭䇭䇭考 Remarks |
数量 Q'ty | R 1 |
R 2 |
R 3 |
| 1 | N610072911AA | BOX | SP60/80:CPU-BOX | 1 | |||
| 2 | N263ZUG2-023 | NOISE-FILTER | ZUG2206- 11S | 1 | S | ||
| 3 | KXFP02JAA00 | CIRCUIT-PROTECTOR | NRF110-8A | 1 | S | ||
| 4 | KXFP005AA00 | FAN | 109-601 | 1 | S | ||
| 5 | KXFP007AA00 | FAN-GUARD | 109-620 | 1 | |||
| 6 | KXFP6EA5A00 | POWER | R100U-5 | 1 | |||
| 7 | KXFP6E8AA00 | POWER | R50A-12 | 1 | S | ||
| 8 | KXFP6EA6A00 | POWER | R15A-12 | 1 | S | ||
| 9 | KXFP6ETXA00 | POWER | R50A-24 | 1 | S | ||
| 10 | N510021558AA | FLASH-DRIVE | SCG3-256MDG | 1 | |||
| 11 | KXFE0062A00 | PCB | MCMAET | 2 | |||
| 12 | KXFE000MA00 | PCB | PRMFEA | 1 | |||
| 13 | KXFE001JA00 | PCB | ELL2EA | 1 | |||
| 14 | N610025429AA | PCB | SCMZEP | 1 | |||
| 15 | KXFE001EA00 | PCB | EC14EA | 1 | |||
| 16 | N610001103AA | PCB | MTMJEB | 1 | |||
| 17 | KXFE0013A00 | PCB | NFM0CN | 1 | |||
| 18 | KXFE002TA00 | PCB | EC55CA | 1 | |||
|
八一>J又卜 PARTS LIST |
士>卜品番 Kit No. |
KXFK000LA01 |
tj)3〉NO. Section No. |
|
士>卜名称 Kit Name |
八口一BOX&配線 Power BOX & Wiring |
2 |
|
4j入卜 NO. Ref No. |
品番 Part No. |
品䇭䇭名 Part Name |
備䇭䇭䇭考 Remarks |
数量 Q'ty | R 1 |
R 2 |
R 3 |
| 1 | N510021031AA | MOTOR-DRIVER | PM-UDSB1504-22 | 1 | |||
| 2 | KXFP5XAAA00 | TERMINAL-BLOCK | BTBH30C8 | 1 | S | ||
| 3 | KXFP699AA00 | TERMINAL-BLOCK | BTBH30C16 | 1 | S | ||
| 4 | KXFP6EBNA00 | TERMINAL-BLOCK | BTBH15C16 | 1 | S | ||
| 5 | KXFP6EBQA00 | MAGNET-CONTACTOR | S-N11 coil AC100V | 1 | S | ||
| 6 | KXFP6FHHA00 | MAGNET-CONTACTOR | UN-AX4(3a1b) | 1 | |||
| 7 | KXFP5C9AA00 | METER | TH632 | 1 | S | ||
| 8 | KXFP6EK2A00 | CIRCUIT-PROTECTOR | CP31V/2DN | 1 | S | ||
| 9 | KXFP6EK3A00 | TRANS | TE1N-700-GR | 1 | |||
| 10 | KXFP6E8AA00 | POWER | R50A-12 | 1 | S | ||
| 11 | KXFP60QAA00 | POWER | LDA300W-24-XKMD | 1 | S | ||
| 12 | KXFP6J1QA00 | CAP | CH45FAUL-C | 1 | S | ||
| 13 | KXFP507AA00 | SWITCH | S-422T | 2 | |||
| 14 | KXFP6CJAA00 | RELAY | HR1S-AF5130 | 2 | S | ||
| 15 | KXFP58LAA00 | CIRCUIT-PROTECTOR | CP31V/5DN | 1 | S | ||
| 16 | KXFP02JAA00 | CIRCUIT-PROTECTOR | NRF110-8A | 2 | S | ||
| 17 | N510005919AA | MOTOR-DRIVER | MBDCT2507B05 | 1 | |||
| 18 | N510005940AA | MOTOR-DRIVER | MADCT1505B05 | 5 | |||
| 19 | N510005941AA | MOTOR-DRIVER | MEDCT5316B05 | 1 | |||
| 20 | N510034769AA | MOTOR-DRIVER | K0707-D | 6 | S | ||
| 21 | KXFP6CTAA00 | CIRCUIT-PROTECTOR | CP33FS/10D | 1 | S | ||
| 23 | KXFE000YA00 | PCB | RL06CA | 1 | |||
