Panasonic CM602 CM402 CM202DS CM301 CM401 Axis Control Board KXFK00APA00 3401P3
Source:未知Author:Smotor Addtime:2023-05-17 Click:
Panasonic CM602 CM402 CM202DS CM301 CM401 Axis Control Board KXFK00APA00 3401P3
パーツリスト
PARTS LIST |
キット品番
Kit No. |
N610022131AA |
ｾｸｼｮﾝNo.
Section No. |
キット名称
Kit Name |
CPU BOX_RoHS
CPU BOX_RoHS |
3 |
ｲﾗｽﾄ
No.
Ref
No. |
品番
Part No. |
品 名
Part Name |
備 考
Remarks |
数量
Q'ty |
R
1 |
R
2 |
R
3 |
|
1 |
KXFP5T3AA00 |
POWER |
R150U-5 |
1 |
|
S |
|
|
2 |
KXFP6EM4A00 |
POWER |
RMC50A- 1 |
1 |
|
S |
|
|
3 |
KXFP005AA00 |
FAN |
109-601 |
1 |
|
S |
|
|
4 |
KXFP007AA00 |
FAN-GUARD |
109-620 |
1 |
|
S |
|
|
5 |
KXFP006AA00 |
FAN-GUARD |
109-619 |
1 |
|
S |
|
|
6 |
KXFP00XAA00 |
CABLE |
489-086-L10 |
1 |
|
S |
|
|
7 |
N263ZUG2-023 |
NOISE-FILTER |
ZUG2206- 11S |
1 |
|
S |
|
|
8 |
KXFE000BA00 |
PCB |
MTL1CA_PbF:LOCAL MOTHER BOARD |
1 |
|
|
|
|
9 |
N510036830AA |
PCB-COM |
660-VME15TKM-VE2 |
1 |
|
|
|
|
10 |
N610012076AA |
PCB |
SCV1ER_PbF:SBC603(150MHz VVB1.0) |
1 |
|
S |
|
|
11 |
N610030275AA |
Board kit |
ELV4EA+ELV3EA |
1 |
|
S |
|
|
12 |
N610001129AA |
PCB |
PRV4EA_PbF:HGR-40 |
1 |
|
S |
|
|
13 |
N610011654AA |
PCB |
PRV4EB_PbF:HGR-40 |
1 |
|
S |
|
|
14 |
KXFK00APA00 |
PCB |
3401P3/Motion Controller:Support for FF |
1 |
|
|
|
|
15 |
N610051792AA |
Board kit |
NF0FCF+NFV2CG |
1 |
|
S |
|
CM202
CM602/CM402/CM202DS/CM301/CM401 AXIS CONTROL BOARD 3401P3 KXFK00APA00
CM402/CM212/CM202DS/CM301 RC BOARD SCV4EB KXFE0009A00
CM212/CM402/CM602 MAIN I/O BOARD NFV2CJ N610140453AA
CM301/CM202D MEMORY BOARD ELV1EA/ELV2EX-1
CM202D PC BOARD SCV1EF
CM301/CM202D I/O BOARD NFV2CA
CM301/CM202D I/O BOARD NFV2CC
CM202 HEAD BOARD MC02CC-7
CM202-D CPU BOARD SCV1EB
CM212
CM212 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM212 PC-COM BOARD 660-VME15TKM-VE2 N510036830AA
CM212 PCB BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM212 PCB BOARD KIT ELV4EA+ELV3EA N610030275AA
CM212 PCB BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM212 PCB BOARDSCV4EB_PbF: HGR14 KXFE0009A00
CM212 PCB BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM212 PCB BOARD KIT NF0FCF+NFV2CG N610051792AA
CM212 PCB BOARD PNF0AF-AA N610012675AA
CM212 PCB BOARD NF5ACA KXFE000KA00
CM212 PCB BOARD NF3ACB N610012673AA
CM212 PCB BOARD PNF0AD-AA N610012674AA
CM212 PCB BOARD NF18CC N610052757AA
CM212 PCB BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM212 PCB BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM212 PCB BOARD NF2ECA KXFE00GTA00
CM212 PCB BOARD MC15CA KXFE0004A00
CM212 PCB BOARD MC14CB KXFE00F0A00
CM212 PCB BOARD MC16CB KXFE00GXA00
CM212 PCB BOARD MS21EA KXFE00GYA00
CM212 PCB BOARD NF8BCA KXFE00EZA00
CM212 PCB BOARD NF3ACB N610012673AA
CM212 PCB BOARD PNF0AD-AA N610012674AA
CM212 PCB BOARD EL1ACA KXFE000JA00
CM212 PCB BOARD PRV5EA_PbF:HGR41-3D N610042291AA
CM212 PCB BOARD PRV5EB_PbF:HGR41-3D N610042292AA
CM301
CM301 I/O BOARD NFOFCE-5/NFV2CD-4
CM301 Axis Control BC386A295H03/MR-MC01-S04/BC386A295G54
CM301 PCB BOARD SLW-1200C
CM301 PC BOARD PR16EA1
CM301 PC BOARD SCV2EE-2
CM301/CM202D MEMORY BOARD ELV1EA/ELV2EX-1
CM301 PC BOARD SCV1EA-4/SCV1EX-4/SCV1EX-9
CM301 PC BOARD PR15EB-2
CM301 PC BOARD NFV2CA
CM301 PC BOARD NFV2CC
CM401
CM401 PC BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM401 PC BOARD NF18CA_PbF:Line Camera Switchover CNT Board KXFE001RA00
CM401 PC BOARD NF2ECA KXFE00GTA00
CM401 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM401 PCB-COM 660-VME15TKM-VE2 N510036830AA
CM401 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM401 PCB BOARD KIT ELV4EA+ELV3EA N610030275AA
CM401 PC BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM401 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM401 PC BOARD KIT NF0FCF+NFV2CG N610051792AA
CM401 PC BOARD PNF0AF-AA N610012675AA
CM401 PC BOARD MC15CA KXFE0004A00
CM401 PC BOARD MC14CB KXFE00F0A00
CM401 PC BOARD MC16CB KXFE00GXA00
CM401 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
CM401 PC BOARD NF3ACB N610012673AA
CM401 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM401 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM401 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM401 PC BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
DT401
DT401 PC BOARD Ceramic PCB Capable(FR Ref;L->R/INR Ref;R->L) KXFX036SA00
DT401 PC BOARD Ceramic PCB Capable(FR Ref;R->L/INR Ref;L->R) KXFX036TA00
CM402
CM402 PC BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM402 PC BOARD NF18CA_PbF:Line Camera Switchover CNT Board KXFE001RA00
CM402 PC BOARD NF2ECA KXFE00GTA00
CM402 MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM402 PCB-COM 660-VME15TKM-VE2 N510036830AA
CM402 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM402 PC BOARD KIT ELV4EA+ELV3EA N610030275AA
CM402 PC BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM402 PC BOARD SCV4EB_PbF: HGR14 KXFE0009A00
CM402 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM402 PC BOARD KIT NF0FCF+NFV2CG N610051792AA
CM402 PC BOARD PNF0AF-AA N610012675AA
CM402 PC BOARD MC15CA KXFE0004A00
CM402 PC BOARD MC14CB KXFE00F0A00
CM402 PC BOARD MC16CB KXFE00GXA00
CM402 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
CM402 PC BOARD NF3ACB N610012673AA
CM402 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM402 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM402 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM402 PCB BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
