Panasonic CM602 CM402 Memory Card N610009178AA N610030275AA ELV4EA ELV3EA（new version））
Source:未知Author:Smotor Addtime:2023-05-17 Click:
Panasonic CM602 CM402 Memory Card N610030275AA ELV4EA ELV3EA
パーツリスト
PARTS LIST |
キット品番
Kit No. |
N610008011AA |
ｾｸｼｮﾝNo.
Section No. |
キット名称
Kit Name |
CPU BOX:VME
CPU BOX:VME |
1 |
ｲﾗｽﾄ
No.
Ref
No. |
品番
Part No. |
品 名
Part Name |
備 考
Remarks |
数量
Q'ty |
R
1 |
R
2 |
R
3 |
|
1 |
KXFP5T3AA00 |
POWER |
R150U-5 |
1 |
|
S |
|
|
2 |
KXFP6EM4A00 |
POWER |
RMC50A-1 |
1 |
|
S |
|
|
3 |
KXFP005AA00 |
FAN |
109-601 |
1 |
|
S |
|
|
4 |
KXFP007AA00 |
FAN-GUARD |
109-620 |
1 |
|
|
|
|
5 |
KXFP6EB5A00 |
NOISE-FILTER |
FN9223-6-06 |
1 |
|
S |
|
|
6 |
KXFP02JAA00 |
CIRCUIT-PROTECTOR |
NRF110-8A |
1 |
|
S |
|
|
7 |
KXFE000BA00 |
PCB |
MTL1CA_PbF:LOCAL MOTHER BOARD |
1 |
|
|
|
|
8 |
KXFP5XHAA00 |
PCB-COM |
650-VME15TO |
1 |
|
|
|
|
9 |
N610012076AA |
PCB |
SCV1ER_PbF:SBC603(150MHz VVB1.0) |
1 |
|
S |
|
|
10 |
N610001129AA |
PCB |
PRV4EA_PbF:HGR-40 |
1 |
|
S |
|
|
11 |
N610011654AA |
PCB |
PRV4EB_PbF:HGR-40 |
1 |
|
S |
|
|
12 |
N610010912AA |
Board kit |
NFV2CF+NF0FCF |
1 |
|
S |
|
|
13 |
KXFK00APA00 |
PCB |
3401P3/Motion Controller: Support for FF |
1 |
|
S |
|
|
14 |
N610009178AA |
Board kit |
ELV3EA+ELV1ED |
1 |
|
|
|
|
15 |
N610010587AA |
UNIT |
|
0 |
|
|
|
|
16 |
N610012025AA |
UNIT |
|
1 |
|
|
|
|
17 |
KXFK002KA00 |
333PC0/LASER I/F |
333PC0/LASER I/F BOX BF : CM402ANRITSU |
1 |
|
|
|
|
18 |
KXFK002LA00 |
333QC0/LASER I/F |
333QC0/LASER I/F BOX BR : CM402ANRITSU |
1 |
|
|
|
|
19 |
KXFE0002A00 |
PCB |
NF0CCA_PbF: Laser_IF |
1 |
|
S |
|
|
|
|
|
|
|
|
|
|
CM402
CM402 PC BOARD PE1ACA_PbF: LED Lighting Control Board N610080208AA
CM402 PC BOARD NF18CA_PbF:Line Camera Switchover CNT Board KXFE001RA00
CM402 PC BOARD NF2ECA KXFE00GTA00
CM402 MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM402 PCB-COM 660-VME15TKM-VE2 N510036830AA
CM402 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM402 PC BOARD KIT ELV4EA+ELV3EA N610030275AA
CM402 PC BOARD SCV4EA_PbF:HGR14 KXFE0008A00
CM402 PC BOARD SCV4EB_PbF: HGR14 KXFE0009A00
CM402 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM402 PC BOARD KIT NF0FCF+NFV2CG N610051792AA
CM402 PC BOARD PNF0AF-AA N610012675AA
CM402 PC BOARD MC15CA KXFE0004A00
CM402 PC BOARD MC14CB KXFE00F0A00
CM402 PC BOARD MC16CB KXFE00GXA00
CM402 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
CM402 PC BOARD NF3ACB N610012673AA
CM402 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM402 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM402 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM402 PCB BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM602
CM602 PC BOARD MTL1CA_PbF:LOCAL MOTHER BOARD KXFE000BA00
CM602 PCB-COM 650-VME15TO KXFP5XHAA00
CM602 PC BOARD SCV1ER_PbF:SBC603(150MHz VVB1.0) N610012076AA
CM602 PC BOARD PRV4EA_PbF:HGR-40 N610001129AA
CM602 PC BOARD PRV4EB_PbF:HGR-40 N610011654AA
CM602 PC BOARD KIT NFV2CF+NF0FCF N610010912AA
CM602 PC BOARD 3401P3/Motion Controller: Support for FF KXFK00APA00
CM602 PC BOARD KIT ELV3EA+ELV1ED N610009178AA
CM602 PC BOARD NF0CCA_PbF: Laser_IF KXFE0002A00
CM602 PC BOARD NF2ACB_PbF: Transport Controller I/O Load Board KXFE00FKA00
CM602 PC BOARD NF5ACA_PbF: Cart stand control board KXFE000KA00
CM602 PC BOARD NF8BCA_PbF: 4-port HUB Board KXFE00EZA00
CM602 PC BOARD NF28CA_PbF: Line CNT Board KXFE000DA00
CM602 PC BOARD PE1ACQ_PbF:LED Lighting Control Board N610017723AC
CM602 PC BOARD NF0ECB_PbF: Ring IO Load Board KXFE000EA00
CM602 PC BOARD MC15CA KXFE0004A00
CM602 PC BOARD MC14CB KXFE00F0A00
CM602 PC BOARD MC16CB KXFE00GXA00
CM602 PC BOARD PMC0AB-AA N610013410AA
CM602 PC BOARD NF3ACA_PbF: Collectively-changing truck controller KXFE000HA00
CM602 PC BOARD EL1ACA_PbF: Conveyor motor (RS485) connection board KXFE000JA00
